5Watt Quad-Band 900/1800/2100/2600MHz Repeater system high power DAS

Name: 5Watt Quad-Band 900/1800/2100/2600MHz Repeater system high power DAS
Brand: Shenzhen Atnj Communication Technology Co., Ltd.
SKU: AT-MS-850/1800/2100
Price: 1,165.00 USD
Availability: InStock

Markenbezeichnung:	ATNJ
Modellnummer:	AT-MS-850/1800/2100
MOQ:	5 Stück
Preis:	USD+1150--1180+kit
Zahlungsbedingungen:	T/T
Versorgungsfähigkeit:	Tag 1000+unit+per.

Ausführliche Information

Produkt-Beschreibung

Ausführliche Information

Herkunftsort:

China

Zertifizierung:

CE,ROHS，CCC，TUV,BV， ISO

Dokument:

Analog Four B8 900+ B3 1...0.docx

900MHz Frequency Range:

880-915MHz / 925-960MHz

1800MHz Frequency Range:

1710-1785MHz / 1805-1880MHz

2100MHz Frequency Range:

1920-1980MHz / 2110-2170MHz

2600MHz Frequency Range:

2496-2690MHz / 2496-2690MHz

Material:

Zinc Alloy ,Plastic

Booster Bandwidth:

Wide Range

Support network:

2G, 3G, 4G, 5G Voice

Booster Warranty:

36 Months

Products Type:

Cellular Signal Booster, amplificadores de seal de celular de 5w

Verpackung Informationen:

Neutrale Standardverpackung

Versorgungsmaterial-Fähigkeit:

Tag 1000+unit+per.

Produkt-Beschreibung

5Watt Quad-Band 900/1800/2100/2600MHz Repeater System

Product Overview

High-power DAS (Distributed Antenna System) repeater supporting 2G, 3G, 4G, and 5G Voice networks across four frequency bands with 5W output power.

Key Specifications

Model: AT-35-L8GDWL26

Frequency Bands: 900MHz, 1800MHz, 2100MHz, 2600MHz

Gain: 90dB

Output Power: 5Watt

Power Supply: AC110V-220V; DC+24V 5A

Connector Type: N-F

Warranty: 36 Months

Detailed Frequency Ranges

Band	Uplink Frequency	Downlink Frequency
Band 8 (900MHz)	880-915MHz	925-960MHz
Band 3 (1800MHz)	1710-1785MHz	1805-1880MHz
Band 1 (2100MHz)	1920-1980MHz	2110-2170MHz
Band 41 (2600MHz)	2469-2690MHz	2469-2690MHz

Technical Specifications

Parameter	Band 8	Band 3	Band 1	Band 41
Bandwidth	35MHz	75MHz	60MHz	221MHz
Max. Gain (Uplink)	80±3 dB	80±3 dB	80±3 dB	80±3 dB
Max. Gain (Downlink)	90±3 dB	90±3 dB	90±3 dB	90±3 dB
Output Power (Uplink)	25±2 dBm	25±2 dBm	25±2 dBm	25±2 dBm
Output Power (Downlink)	35±2 dBm	35±2 dBm	35±2 dBm	35±2 dBm

Additional Specifications

Dimensions: 416×268×88mm

Weight: ≤15kg

IP Rating: IP40

Operating Temperature: -25°C to 55°C

Power Consumption: ≤85W

Certifications: CE, ROHS

Key Features

♦ Supports 2G, 3G, 4G, and 5G Voice networks simultaneously
♦ Automatic Level Control (ALC) and Automatic Gain Control (AGC) functions
♦ Reduces mobile device radiation in weak signal areas
♦ No limit to number of supported mobile devices
♦ Suitable for remote areas with available signal source

System Components

♦ Outdoor Antenna: Receives signal from base station
♦ Signal Booster: Amplifies the received signal
♦ Indoor Antenna: Distributes amplified signal indoors
♦ Jump Cable: Connects antennas to booster

Product Images

Frequently Asked Questions

Q: Do you have CE or any other certification?

A: Yes, we have CE and ROHS certifications.

Q: How about gain and output power of your device?

A: This model features 90dB gain and 5W output power. Specifications vary by model.

Q: Can I use your device in suburbs or remote areas?

A: Yes, our signal booster can help solve signal problems in remote areas when a signal source is available.
